Hinged Glass Doors

Wood-Alu

Hinged-glass-doors-with-picture-windows

Specifications

  • Internal IV68mm timber frame, low VOC spray-painted or stained in the colour of your choice
  • External aluminium cladding powder-coated in a wide range of colours
  • Timber and cladding separated by 3mm clip system to stop condensation and subsequent rot
  • Triple glazed 2x up to 16mm or double glazed 1x up to 22mm argon filled gap
  • Choice of glass combinations
  • Custom made
  • German hardware, multi-point locking
  • Manual or automatic operation available
  • Seals to eliminate drafts
  • High energy efficiency and sound protection
  • Suited for bushfire areas up to and including BAL-29, and Passive House

Size:

  • Width up to 1400mm
  • Height up to 3000mm

WERS energy rating: U-value from a very low 1.0
