4 x AGWA Design Awards in 2024: Beach Retreat NSW State and National; Clifton Hill Passive House Primary School VIC State and National.
Giant Lift-Slide Doors
Architectural Timber Range
Specifications
- IV 78mm timber frame, triple glazed with 2x 12-16mm argon filled gap
- IV 68mm timber frame, double glazed with 1x 14-20mm argon filled gap
- Choice of glass combinations
- German lift and slide hardware fittings
- Custom made to many configurations
- Scheme A and Scheme C can be fitted with the patented Siegenia HS Lift & Slide Automation
- Low VOC spray-painted or stained in the colour of your choice
- Multi-layer seals and night vent
- High energy efficiency and sound protection, draft free
- Suited for bushfire areas up to and including BAL-29, and for Passive House
Size:
- Weight up to 400kg per slider
- Slider width up to 3.6m at a maximum of 8.8m2 per leaf
- Height up to 3.4m at a maximum of 8.8m2 per leaf
- Overall width by request
WERS energy rating: U-value from a very low 1.0
Door Configurations
Technologically advanced lift-slide sliding doors are available in a variety of configuration:
For stacking sliding doors see Stacker Lift-slide Doors
For corner sliding doors see Corner Lift-Slide Doors
